Intelligent Cleaning Mop Robot
QJ-15 Intelligent Cleaning Robot for Autonomous Commercial Floor Cleaning
The QJ-15 Intelligent Cleaning Robot is a fully autonomous commercial cleaning solution designed for large indoor environments. Powered by SLAM and V-SLAM fusion navigation, combined with Lidar and 3D camera obstacle avoidance, the QJ-15 delivers precise sweeping, mopping, and vacuuming with minimal human intervention.
It is widely deployed in offices, warehouses, shopping malls, airports, hospitals, and other high-traffic commercial spaces. The cloud-based management platform enables remote task deployment, multi-zone scheduling, and real-time monitoring, supporting fully unmanned and efficient cleaning operations.
Key Features
3-in-1 Cleaning: Sweeping, Mopping, and Vacuuming
SLAM + V-SLAM high-precision autonomous navigation
Lidar + 3D camera intelligent obstacle avoidance system
Optimized cleaning routes with wall-following and full coverage algorithms
Cloud-based management platform for remote deployment and monitoring
Supports multi-zone and multi-task cleaning on a single map
Water disinfection and filtration system to reduce water consumption
Scheduled cleaning with automatic task execution
Adjustable cleaning speed: 0.2–0.4 m/s
Modular design for easy maintenance and servicing
Large-scale mapping capability up to 40,000 m²
37V / 20Ah lithium battery with 4–6 hours runtime
Automatic return to charging station when battery is low
User authority verification and maintenance reminders
Technical Specifications
| Item | Specification |
|---|---|
| Cleaning Modes | Sweeping / Mopping / Vacuuming (3-in-1) |
| Navigation System | SLAM + V-SLAM Fusion Navigation |
| Obstacle Avoidance | Lidar + 3D Camera |
| Cleaning Speed | 0.2–0.4 m/s |
| Battery | 37V / 20Ah Lithium Battery |
| Runtime | 4–6 Hours (depending on environment and mode) |
| Maximum Mapping Area | Up to 40,000 m² |
| Charging Method | Automatic Return to Charging Station |
| Management Platform | Cloud-based Remote Management System |
| User Security | User Authority Verification & Identity Management |
Frequently Asked Questions (FAQ)
Can the QJ-15 operate without human intervention?
Yes. The QJ-15 supports fully autonomous cleaning, including intelligent route planning, obstacle avoidance, automatic return to charging, and cloud-based remote management.
Does the QJ-15 support multi-zone cleaning?
Yes. Multiple cleaning tasks can be assigned across different zones within the same floor map.
How accurate is the navigation system?
SLAM and V-SLAM fusion navigation combined with Lidar and 3D camera enables centimeter-level positioning accuracy.
How long can the robot operate on a single charge?
The typical runtime is 4–6 hours, depending on cleaning mode and environmental conditions.
Can multiple QJ-15 robots be managed together?
Yes. The cloud management platform allows centralized monitoring, scheduling, and task deployment for multiple robots.
Is it suitable for nighttime cleaning?
Yes. Scheduled cleaning allows unattended operation during nighttime or off-hours.
For more information, technical datasheets, or pricing details, please contact our sales team to receive the full product catalog.
